GRLevel3 Doppler Radar

Base Reflectivity

This is a display of echo intensity (reflectivity) measured in dBZ. The base reflectivity images in Precipitation Mode are available at four radar "tilt" angles, 0.5°, 1.45°, 2.40°, and 3.35° (these tilt angles are slightly higher when the radar is operated in Clear Air Mode). A tilt angle of 0.5° means that the radar's antenna is tilted 0.5° above the horizon. Viewing multiple tilt angles can help one detect precipitation, evaluate storm structure, locate atmospheric boundaries, and determine hail potential.

The maximum range of the "short range" base reflectivity product is 124 nautical miles (about 143 miles) from the radar location. This view will not display echoes that are more distant than 124 nm, even though precipitation may be occurring at greater distances.
